Onkyo TX-NR696 7.2 Channel Network AV Receiver

TX-NR696 Onkyo TX-NR696 7.2 Channel Network AV Receiver-1 TX-NR696 Onkyo TX-NR696 7.2 Channel Network AV Receiver-2 TX-NR696 Onkyo TX-NR696 7.2 Channel Network AV Receiver-3 TX-NR696 Onkyo TX-NR696 7.2 Channel Network AV Receiver-4
TX-NR696 Onkyo TX-NR696 7.2 Channel Network AV Receiver

Onkyo TX-NR696 7.2 Channel Network AV Receiver

(1) SKU: 111619548 MODEL: TX-NR696
Onkyo Logo
Please note: This item is not currently available online and may not become available again.
Out Of Stock Icon

Out Of Stock

Overview

A harmonious mix of tech and tradition at RC Willey, the Onkyo TX-NR696 7.2 channel network AV receiver adapts to entertainment life and finds the emotion in every sound source, from 3D film-scores to vinyl records. The SMART AV Receiver gathers Chromecast built-in, Works with Sonos, AirPlay 2, and DTS Play-Fi with streaming services for smooth multi-room audio evolved by support for the new high-speed 802.11ac (2x2 MIMO) Wi-Fi specification. Dolby Atmos and DTS:X pull audiences deep into movies and games, THX Certified Select assuring a theater-reference experience. If a 5.2.2-ch setup isn’t possible, Dolby Atmos Height Virtualizer and DTS Virtual:X can create a 3D sound-field from horizontal speaker layouts. Separate Zone 2 outputs with switching also enable 7-ch layouts in Main plus Zone 2 speakers. With a revitalized DAA system, 4K/60p/HDR HDMI terminals, and many extras, this product excels in every aspect

Features

  • Product Features: 7.2ch, 100w/Ch Thx Certified Select Daa Receivr
  • Smart Av Receiver-works With Sonos,Chromecast
  • Built-in, Airplay 2, DTS Play-fi, More
  • Supports 5.2.2 Dolby Atmos and DTS:x Playback
  • HDmi 6 In /2 Out , Wifi, Bluetooth 4.1,
  • Powered Zone 2
  • 4k Passthrough
  • Zone 2/Zone B line-out with DAC shares D/A audio (including HDMI/SPDIF)
  • Separate Zone 2 outputs distribute D/A audio sources (including HDMI/SPDIF)
  • Stereo Assign Mode to switch Front playback to Height channels
  • DSP-based Vocal Enhancer improves dialog audibility
  • GUI with OSD via HDMI features media input/output data display function
  • HDMI supports 4K/60p, 4K HDR, 4:4:4/24-bit, BT.2020, HDCP 2.2
  • AccuEQ Advance with AccuReflex
  • One-touch volume memory-presets for A/V inputs

Specs

Model TX-NR696
Dimensions 17"W x 15"D x 7"H
Weight 22 lbs.
Amplifier Section
All Channels 100 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC) 210 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)
Dynamic Power 240 W (3 Ohms, Front) 210 W (4 Ohms, Front) 120 W (8 Ohms, Front)
THD + N (Total Harmonic Distortion + Noise) 0.08% (20 Hz–20 kHz, Half Power)
Input Sensitivity and Impedance 200 mV / 47k Ohms (Line/Unbalanced) 3.5 mV/47k Ohms (Phono/MM)
Rated RCA Output Level and Impedance 200 mV / 2.3k Ohms (Zone B/ Zone 2 Line Out) 1 V / 470 Ohms (Subwoofer Pre Out)
Phono Overload 70 mV (MM, 1 kHz, 0.5%)
Frequency Response 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
Tone Control ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 106 dB (Line, IHF-A) 80 dB (Phono, IHF-A)
Speaker Impedance 4 Ohms–16 Ohms
Video Section
Video 1.0 Vp–p/75 Ohms (Component Y) 0.7 Vp–p/75 Ohms (Component PB/CB, PR/CR) 1.0 Vp–p/75 Ohms (Composite)
Component Video Frequency Response +0 dB, -3 dB
Tuner Section
FM 87.5 MHz–107.9 MHz
AM 530 kHz–1,710 kHz
FM/AM Preset Memory 40 Stations
General
Power Supply AC 120 V~, 60 Hz
Power Consumption 635W
No-Sound Power Consumption 65W
Standby Power Consumption 0.15W
