Magnum Pathfinder 48-Volt, 500W Electric Bike - Forest Green
Magnum Pathfinder 48-Volt, 500W Electric Bike - Forest Green
Best Online Price. Includes All Discounts and Sales
Options
Assembly Required
Assembly Required.
Magnum Summit Electric Bike with 27.5" Wheels - Blue and Black
See Price In Cart
- 20" Fat tire
- Fully integrated battery
- Small frame - great fit for riders under 5'4"
Collection | Magnum |
---|---|
Weight | 70 lbs. |
Color | Forest |
Body Position | Upright |
Max Load | 265lbs |
Electronic Details | |
Motor Type | Rear Geared Hub Motor |
Motor Output | 48v 500w |
Battery Voltage/Amp Hours/Watt Hours | 48v/13ah/624wh |
Battery Chemistry | Lithium Nickel Cobalt Manganese (Li-ncm) |
Estimated Charge Time | 4-4.5 Hours |
Estimated Min and Max Range | 30 to 50 Miles (Depending on Riding Style, Terrain, Rider Weight and Pedal Assist Level) |
Display Type | Bigstone H102 Display |
Display Readouts | Speed, Front Light On/Off, Assist Level 0-3, Battery Level, Odometer, Trip Distance, Range |
Drive Modes | Pedal Assist, Twist Throttle |
Max Speed | 25mph |
Lights | Integrated Front and Rear Light Controlled by the Display |
Bicycle Details | |
Total Weight | 50lbs |
Battery Weight | 8lbs |
Frame Type | Low Step |
Fork Details | Fixed Alloy |
Gearing Details | Shimano Altus 7 Speed |
Shifter Details | Shimano Altus |
Stem | Adjustable Alloy |
Brake Details | Tekro Hydraulic Disc Brakes |
Saddle | VELO Saddle |
Seatpost | Rigid |
Rack/Fenders | Rear Rack, Front and Rear Fenders |
Tires | Innova 20" Fat Tire |
Wheel Size | 20" x 3" |
Dimensions | |
Max Seat Height *Measured from the bottom pedal stroke | 36" |
Min Seat Height *Measured from the bottom pedal stroke | 26" |
Seat Tube | 15" |
Standover Height | 14.5" |
Handlebar Height | 39" - 41.5" |
Handlebar Width | 24" |
Total Length | 66" |
Wheelbase | 44" |
Manufacturer Warranties
- 1-Year Manufacturer's Warranty
